ASP-52016
01
Model No.
ASP-52016
02
Component Cell
9299130N w/STOBA in side
03
Connection Structure
14S1P
04
Positive Material
LiCoxNiyMnzO
05
Typical Capacity
16Ah
06
Cycle Life
0.5C - 1C RT > 500 / 100% DOD
07
Voltage
Average
51.1V
Max.
58.8V
Min.
42.0V
08
Discharge
Transient Peak Current
30A
09
Dimension
Thickness/Height
182.7 mm
Width
109.6 mm
Length
165.4 mm
10
Weight
<5KG
11
Energy/Rated Capacity
1.5 KWh
12
Charge
Max.Current
16A
13
Operating Temperature
Charging
10~45℃
Discharging
0~55℃
14
Storage Temperature
0~40℃
15
Humidity Range
< RH 45~85%
